Note: DEFAULT values are based on user selecting usa on the setup menu.
To access the remaining parameters, use the setting dial to scroll through the programming menu until you see
f4--. Hit the enter button, and then scroll to the parameter numbers to make changes.
PARAMETER DESCRIPTION DEFAULT ADJUSTMENT RANGE
f405
Motor Rated Capacity --- kW
0.01-22.0 kW
f415
Motor Rated Current --- A
0.01-100.0 A
f417
Motor Rated Speed 1710 RPM
100-64000 RPM
f701
Current/Voltage Unit Selection 0: %
0: %
1: A/V
Revision History:
Rev. Date Written/Revised
By
Approved By Description
0 7/29/2015 Joshua Austin Felipe Reyna Original Document.
For additional assistance, please contact Toshiba Adjustable Speed Drive Marketing Dept. at (855) 803-7089.
Website: www.toshiba.com/tic YouTube: TICTalk - https://www.youtube.com/user/ToshibaIndustrial
PARAMETER DESCRIPTION DEFAULT ADJUSTMENT RANGE
fmod
Frequency Setting Mode Selection 1
(Frequency Reference)
0: Setting dial 1
0: Setting dial 1
1: Terminal VIA (0-10Vdc)
2: Terminal VIB (0-10Vdc)
3: Setting dial 2
4: RS485 Communication
5: UP/DOWN from external logic input
6: CANopen Communication
7: Communication Option
8: Terminal VIC (4-20mA)
11: Pulse Train Input
14: sr0
acc
Acceleration Time 1 10.0 s
0.0-3600 s
dec
Deceleration Time 1 10.0 s
0.0-3600 s
ul
Upper Limit Frequency 60.0 Hz
0.5-fh Hz
ll
Lower Limit Frequency 0.0 Hz
0.0-ul Hz
vl
Base Frequency 1 60.0 Hz
20.0-500.0 Hz
vlv
Base Frequency Voltage 1
230 (230V class)
460 (460V class)
50-330 (230V class)
50-660 (460V class)
pt
V/Hz Control Mode Selection 0: Constant Torque
0:Constant Torque
1:Variable Torque
2: Automatic Torque Boost Control
3: Vector Control
4: Energy-Saving
5: Dynamic Energy-Saving
6: PM Motor Control
7: V/F 5-Point Control
thr
Motor Electronic Thermal-Protection
Level 1
100 %
10-100 %
