Do not block the cooling vents. Keep foreign metal objects, such as
screws, staples, and paper clips, out of the cooling vents. Foreign metal
objects can create a short circuit, which can cause damage and fire,
possibly resulting in serious injury.
Carefully clean the dust on the surface of the cooling vents using a soft
cloth.
Memory module
cover
Some models are equipped with the memory
module cover. The memory module slot under
this cover allows for the installation, replacement
and removal of additional memory module.
The capacity of the memory modules varies
depending on the model. The actual amount of
useable system memory is less than the installed
memory modules.
Refer to the Additional memory module section.
Front with the display open
This section shows the computer with the display panel open. In order to
open the display, lift up the display panel and position it at a comfortable
viewing angle for you.
Figure 3-6 The front of the computer with the display panel open
5
8
7
9
8
11
1 2 3
4
6
10
14
13
14
13
A B
12
User's Manual 3-6
