8. Seat the memory module cover in place and secure it with the screw.
Take care to ensure that the memory module cover is firmly closed.
Figure 4-8 Seating the memory module cover
1. Memory module cover 2. Screw
9. Turn your computer over.
10. Connect the AC adaptor and turn on the computer. Make sure that the
added memory is recognized. To confirmed it, click Control Panel ->
System and Security -> System under Windows System group in
All apps.
Removing a memory module
To remove the memory module, do the following:
1. Click Start -> Power and then select Restart.
2. Hold down the F2 key and then release this key one second after the
computer is power on. The TOSHIBA Setup Utility will load.
In the TOSHIBA Setup Utility screen, select Exit -> Disable Built-in
Battery, and Power Off.
3. Remove the AC adaptor, all cables, and peripherals connected to the
computer.
4. Close the display panel and turn the computer upside down.
5. Loosen the screw securing the memory module cover in place. Note
that the screw is attached to the cover in order to prevent it from being
lost.
6. Slide your fingernail or a thin object under the cover and lift it off.
7. Push the latches away from the module in order to release it. A spring
forces one end of the module up at an angle.
User's Manual
4-27
