ApplicationNote
Page6
;************************************************
;TABLESANDDATA
;Initializationbytesfor240x64
msgi1:
db80h,07h,40h;texthomeaddress
db1eh,00,41h;textarea
db00,00,42h;graphichomeaddress
db1eh,00,43h;graphicarea
db00,00,81h;modeset
db00,00,24h;addresspointerset
db00,00,98h;displaymodeset
db0a1h
msgi2:
db00,00,0b0h;automode
db0a1h
;240x64Bitmapgraphicdata
;Onlythefirst8bytesareshownhere
;Therealgraphicconsistsof1920bytes
;ofbinarydata.
msg1:
db00h,00h,00h,00h,00h,00h,00h,00h
db0a1h
end
