TC Series (TCmini/TC200) Driver
GP-Pro EX Device/PLC Connection Manual
26
Procedure
1 On the computer, start the ladder software.
2 From the [Tool] menu, select [Register editor].
The [Register data] window appears.
3 Set the register as follows.
Double-click [HEX] in the register column and enter the value in the [Data change] dialog box.
CPU Register Setting
TC3-01 D11F 0004h
TC8-00 D37F 8004h
• The following items are fixed. The communication speed is set automatically.
Setting Information Value
Communication Type RS-422/485 (2wire)
Data Length 8 bit
Parity None
Stop Bit 2 bit
To Next Page
