6.4 Spare parts list (TDP-P9, TDP-PX10) GREEN
P9 PX10
1 - SCREW, M2*4*A1.3 B
2 - SCREW, M2.5*4*E0.7 NI
3 - SCREW, M2.5*6*A1.7 NI
4 - SCREW, M3*6*A2 NI
5 - SCREW, M3*26*D2 NI
6 - SCREW, M3*23*E1.2 BL
7 A1 CASE, SOFT
8A2CARTON
9 A3 PAD, CARTON
10 A4 LABEL, LAMP
11 A5 LABEL, LENS
12 A6 LABEL, LAMP BURSTING
----- 75010682
13 A7 PAD
14 A8 LABEL, RATING
----- 75010681
15 A9 LABEL, WARNING
16 A10 MANUAL, QUICK GUIDE, P9, VER2
17 A11 LABEL, HOT WARNING
18 A12 STRAP, LENS CAP
19 A13 CABLE, RGB
20 A14 CORD, POWER, US
21 A15 CORD, POWER, EU
75010626 -----
22 A17 CORD, POWER, UK
75010628 -----
23 A19 USERS MANUAL, CD-ROM, P9, VER2
75011046 -----
24 A20 USER'S MANUAL, CD-ROM, PX10, VER2
----- 75011147
25 A21 CORD, POWER, CHINA
75011044 -----
26 B1 PC BOARD ASSY, MAIN, P9
27 B2 PC BOARD ASSY, BALLAST
28 B3 PC BOARD ASSY, MAIN POWER
29 B4 KEYPAD
30 B5
PC BOARD ASSY, IR
31 B6 PC BOARD ASSY, PHOTO SENSOR
32 B7 PC BOARD ASSY, DMD
33 C1 COVER, TOP, P9
34 C2
COVER, FRONT, P9 75010669 -----
35 C2
COVER, FRONT, PX10 ----- 75010684
36 C3 COVER, BOTTOM
37 C4
COVER, LAMP
38 C5
COVER, LENS
39 C7 PLATE, DECORATION CIRCLE
40 C8
COVER, IR, FRONT
41 C9
FOOT ASSY, FRONT
42 C10 FOOT ASSY, REAR
43 C11
COVER, IO
44 C12 COVER, IR, REAR
45 F1
FAN, AFB0512VHD-7F49
46 F2
FAN, AUB0512HHB-7G27
47 F3
FAN, BUB04512MD
48 M1
SPEAKER
49 M2
MYLAR, BALLAST
50 M3
SPONGE FAN5015
No
Loca-
tion
Description
Part No
75010621
75010622
75010652
75010614
75010615
75010616
75010619
75010666
75010667
75010670
75010680
75010671
75010668
75010641
75010645
75010663
75010810
75010673
75010678
75010676
75010675
75010624
75010625
75010649
75010655
75010664
75010665
75010679
75010639
75010642
75010651
75010659
75010627
75010629
75010677
75011045
75010654
75010656
75010658
75010660
75010653
