59
Others
58
Specifications (Continued)
■ CONTROL terminal
● Pin assignment
7
68
5
4
3
2
1
Signal Name
RXD
CTS
DSR
GND
RTS
N.C
TXD
GND
Pin No.
1
2
3
4
5
6
7
8
Description
Receiving data
Consent to send
Data set ready
Signal ground
Request to send
No connection
Sending data
Signal ground
Mini DIN 8 pin connector
● Interface format
1 Communication method RS-232C, 9600bps, No Parity, Data Length: 8 bits;
Stop Bit Length: 1 bit
2 Communication format STX (02h) Command (3Byte) ETX (03h)
Only 1 command valid per communication.
3 Data format For input commands, only ASCII-compliant all-uppercase
alphanumeric characters supported.
4 Replies Acknowledge ACK (06h) CR (0Dh) Data ... Normally ended
ACK (06h) ESC (1Bh) ... Aborted
No acknowledge NAK (15h)
If commands are to be sent consecutively, wait for the response from the projector
before sending the next command.
● Main Commands
Item Command
Power on PON
Power off POF
Icon display on MO0
Icon display off MO1
Auto setting (RGB input) PAT
Status display on DON
Status display off DOF
Note
• Contact your dealer for control cable and other commands.
■ Separately sold product
Replacement Lamp Model TLPLW11
■ List of supported signals (Y/PB/PR signals)
Signal format fh(kHz) fv(Hz)
480i(525i)@60Hz 15.73 59.94
480p(525p)@60Hz 31.47 59.94
576i(625i)@50Hz 15.63 50.00
576p(625p)@50Hz 31.25 50.00
720p(750p)@60Hz 45.00 60.00
720p(750p)@50Hz 37.50 50.00
1080i(1125i)@60Hz 33.75 60.00
1080i(1125i)@50Hz 28.13 50.00
■ List of supported signals (Video, S-Video signals)
Video mode fh(kHz) fv(Hz) fsc(MHz)
NTSC 15.73 60 3.58
PA L 15.63 50 4.43
SECAM 15.63 50 4.25 or 4.41
PAL-M 15.73 60 3.58
PAL-N 15.63 50 3.58
PAL-60 15.73 60 4.43
NTSC4.43 15.73 60 4.43
■ Pin assignment of COMPUTER 1 IN, COMPUTER 2 IN &
MONITOR OUT terminals
1115
6
15
10
Input Signal
• RGB input
RGB signals: 0.7V (p-p) 75 Ω
Horizontal sync signal
: TTL level (Pos/neg polarity)
Vertical sync signal: TTL level (Pos/neg polarity)
• Y/P
B/PR input
Y signal: 1.0V (p-p) 75 Ω
P
B/PR signals: 0.7V (p-p) 75 Ω
Mini D sub 15 Pin connector
Pin Pin description
No. During RGB input During Y/P
B
/P
R
input
1 Video signal (R) Color difference signal (P
R
)
2 Video signal (G) Luminance signal (Y)
3 Video signal (B) Color difference signal (P
B
)
4 GND ∗
5 GND ∗
6GND (R) GND (P
R
)
7GND (G) GND (Y)
8GND (B) GND (P
B
)
9 N.C ∗
10 GND ∗
11 GND ∗
12 N.C ∗
13 Horizontal sync signal ∗
14 Vertical sync signal ∗
15 N.C ∗
∗ Do not connect anything.
