Toshiba Tosvert VF-S15 Quick Start Manual

38
E6582383
E6582383
3
Current reduction
According to the carrier frequency f300 setting, you may need to reduce the inverter’s continuous output current.
Reduction rates vary depending on the capacity of the inverter.
[Single-phase/Three-phase 200/240V class]
Inverter model Ambient temperature
Input voltage 200V to 240V
PWM carrier frequency
2.0k to 4.0kHz 4.1k to 12.0kHz
VFS15-2002PM
VFS15S-2002PL
40°C or less
1.5 A
VFS15-2004PM
VFS15S-2004PL
40°C or less
3.3 A
VFS15-2007PM
VFS15S-2007PL
40°C or less
4.8 A
VFS15-2015PM
VFS15S-2015PL
40°C or less
8.0 A 7.9 A
Above 40 to 50°C
8.0 A
VFS15-2022PM
VFS15S-2022PL
40°C or less
11.0 A 10.0 A
Above 40 to 50°C
11.0 A
Note ) For 0.75 kW or less in 200/240 V class, maintain the ambient temperature of 40°C or less and the PWM carrier
frequency of 4kHz or less for the compliance with UL standard.
Note ) For "Above 40°C to 50°C" of the ambient temperature except 0.75 kW or less in 200/240 V class, remove the
protective label on the top of the inverter for the compliance with UL standard.
[Three-phase 200/240V class]
Inverter model Ambient temperature
Input voltage 200V to 240V
PWM carrier frequency
2.0k to 4.0kHz 4.1k to 12.0kHz
VFS15-2037PM
40°C or less
17.5 A 16.4 A
Above 40 to 50°C
17.5 A
VFS15-2055PM
40°C or less
27.5 A 25.0 A
Above 40 to 50°C
27.5 A
VFS15-2075PM
40°C or less
33.0 A 33.0 A
Above 40 to 50°C
33.0 A
VFS15-2110PM
40°C or less
54.0 A 49.0 A
Above 40 to 50°C
54.0 A
VFS15-2150PM
40°C or less
66.0 A 60.0 A
Above 40 to 50°C
66.0 A
Note 2) For "Above 40°C to 50°C" of the ambient temperature, remove the protective label on the top of the inverter for
the compliance with UL standard.
E6582383
4
[Three-phase 400/500V class]
Inverter model
Ambient
temperature
Input voltage 380V to 480V
Input voltage
A
bove 480V to 500V
PWM carrier frequency PWM carrier frequency
2.0k to 4.0kHz
4.1k to 12.0kHz
2.0k to 4.0kHz
4.1k to 12.0kHz
VFS15-4004PL
40°C or less
1.5 A 1.5 A
1.5 A 1.5 A
Above 40 to 50°C
1.5 A
1.5 A
VFS15-4007PL
40°C or less
2.3 A 2.1 A
2.1 A 1.9 A
Above 40 to 50°C
2.3 A
2.1 A
VFS15-4015PL
40°C or less
4.1 A 3.7 A
3.8 A 3.4 A
Above 40 to 50°C
4.1 A
3.8 A
VFS15-4022PL
40°C or less
5.5 A 5.0 A
5.1 A 4.6 A
Above 40 to 50°C
5.5 A
5.1 A
VFS15-4037PL
40°C or less
9.5 A 8.6 A
8.7 A 7.9 A
Above 40 to 50°C
9.5 A
8.7 A
VFS15-4004PL1
40°C or less
1.5 A 1.5 A
Above 40 to 50°C
1.5 A
VFS15-4007PL1
40°C or less
2.3 A 2.1 A
Above 40 to 50°C
2.3 A
VFS15-4015PL1
40°C or less
4.1 A 3.7 A
Above 40 to 50°C
4.1 A
VFS15-4022PL1
40°C or less
5.5 A 5.0 A
Above 40 to 50°C
5.5 A
VFS15-4037PL1
40°C or less
9.5 A 8.6 A
Above 40 to 50°C
9.5 A
VFS15-4055PL
40°C or less
14.3 A 13.0 A
Above 40 to 50°C
14.3 A
VFS15-4075PL
40°C or less
17.0 A 17.0 A
Above 40 to 50°C
17.0 A
VFS15-4110PL
40°C or less
27.7 A 25.0 A
Above 40 to 50°C
27.7 A
VFS15-4150PL
40°C or less
33.0 A 30.0 A
Above 40 to 50°C
33.0 A
Note ) For "Above 40°C to 50°C" of the ambient temperature, remove the protective label on the top of the inverter for the
compliance with UL standard.
Note ) VFS15-4004PL ~ 4037PL don't comply with UL61800-5-1, comply with UL508C.
[Three-phase 600V class] (only -W1 model)
Inverter model
Ambient
temperature
Input voltage
525V to 600V
PWM carrier
frequency
2.0k to 4.0kHz
4.1k to 12.0kHz
VFS15-6015P
40°C or less
2.7 A
Above 40 to 50°C
2.7 A
VFS15-6022P
40°C or less
3.9 A
Above 40 to 50°C
3.9 A
VFS15-6037P
40°C or less
6.1 A
Above 40 to 50°C
6.1 A
VFS15-6055P
40°C or less
9.0 A
Above 40 to 50°C
9.0 A
VFS15-6075P
40°C or less
11.0 A
Above 40 to 50°C
11.0 A
VFS15-6110P
40°C or less
17.0 A
Above 40 to 50°C
17.0 A
VFS15-6150P
40°C or less
22.0 A
Above 40 to 50°C
22.0 A
Note ) For "Above 40°C to 50°C" of the ambient temperature, remove the protective label on the top of the inverter for
the compliance with UL standard.
Note ) Be sure to connect a line inductance, refer to Table 4 for the value.
VF-S15_QS.indb 38VF-S15_QS.indb 38 2021/11/18 15:51:492021/11/18 15:51:49
39
E6582383
E6582383
3
Current reduction
According to the carrier frequency f300 setting, you may need to reduce the inverter’s continuous output current.
Reduction rates vary depending on the capacity of the inverter.
[Single-phase/Three-phase 200/240V class]
Inverter model Ambient temperature
Input voltage 200V to 240V
PWM carrier frequency
2.0k to 4.0kHz 4.1k to 12.0kHz
VFS15-2002PM
VFS15S-2002PL
40°C or less
1.5 A
VFS15-2004PM
VFS15S-2004PL
40°C or less
3.3 A
VFS15-2007PM
VFS15S-2007PL
40°C or less
4.8 A
VFS15-2015PM
VFS15S-2015PL
40°C or less
8.0 A 7.9 A
Above 40 to 50°C
8.0 A
VFS15-2022PM
VFS15S-2022PL
40°C or less
11.0 A 10.0 A
Above 40 to 50°C
11.0 A
Note ) For 0.75 kW or less in 200/240 V class, maintain the ambient temperature of 40°C or less and the PWM carrier
frequency of 4kHz or less for the compliance with UL standard.
Note ) For "Above 40°C to 50°C" of the ambient temperature except 0.75 kW or less in 200/240 V class, remove the
protective label on the top of the inverter for the compliance with UL standard.
[Three-phase 200/240V class]
Inverter model Ambient temperature
Input voltage 200V to 240V
PWM carrier frequency
2.0k to 4.0kHz 4.1k to 12.0kHz
VFS15-2037PM
40°C or less
17.5 A 16.4 A
Above 40 to 50°C
17.5 A
VFS15-2055PM
40°C or less
27.5 A 25.0 A
Above 40 to 50°C
27.5 A
VFS15-2075PM
40°C or less
33.0 A 33.0 A
Above 40 to 50°C
33.0 A
VFS15-2110PM
40°C or less
54.0 A 49.0 A
Above 40 to 50°C
54.0 A
VFS15-2150PM
40°C or less
66.0 A 60.0 A
Above 40 to 50°C
66.0 A
Note 2) For "Above 40°C to 50°C" of the ambient temperature, remove the protective label on the top of the inverter for
the compliance with UL standard.
E6582383
4
[Three-phase 400/500V class]
Inverter model
Ambient
temperature
Input voltage 380V to 480V
Input voltage
A
bove 480V to 500V
PWM carrier frequency PWM carrier frequency
2.0k to 4.0kHz 4.1k to 12.0kHz 2.0k to 4.0kHz 4.1k to 12.0kHz
VFS15-4004PL
40°C or less
1.5 A 1.5 A
1.5 A 1.5 A
Above 40 to 50°C
1.5 A
1.5 A
VFS15-4007PL
40°C or less
2.3 A 2.1 A
2.1 A 1.9 A
Above 40 to 50°C
2.3 A
2.1 A
VFS15-4015PL
40°C or less
4.1 A 3.7 A
3.8 A 3.4 A
Above 40 to 50°C
4.1 A
3.8 A
VFS15-4022PL
40°C or less
5.5 A 5.0 A
5.1 A 4.6 A
Above 40 to 50°C
5.5 A
5.1 A
VFS15-4037PL
40°C or less
9.5 A 8.6 A
8.7 A 7.9 A
Above 40 to 50°C
9.5 A
8.7 A
VFS15-4004PL1
40°C or less
1.5 A 1.5 A
Above 40 to 50°C
1.5 A
VFS15-4007PL1
40°C or less
2.3 A 2.1 A
Above 40 to 50°C
2.3 A
VFS15-4015PL1
40°C or less
4.1 A 3.7 A
Above 40 to 50°C
4.1 A
VFS15-4022PL1
40°C or less
5.5 A 5.0 A
Above 40 to 50°C
5.5 A
VFS15-4037PL1
40°C or less
9.5 A 8.6 A
Above 40 to 50°C
9.5 A
VFS15-4055PL
40°C or less
14.3 A 13.0 A
Above 40 to 50°C
14.3 A
VFS15-4075PL
40°C or less
17.0 A 17.0 A
Above 40 to 50°C
17.0 A
VFS15-4110PL
40°C or less
27.7 A 25.0 A
Above 40 to 50°C
27.7 A
VFS15-4150PL
40°C or less
33.0 A 30.0 A
Above 40 to 50°C
33.0 A
Note ) For "Above 40°C to 50°C" of the ambient temperature, remove the protective label on the top of the inverter for the
compliance with UL standard.
Note ) VFS15-4004PL ~ 4037PL don't comply with UL61800-5-1, comply with UL508C.
[Three-phase 600V class] (only -W1 model)
Inverter model
Ambient
temperature
Input voltage
525V to 600V
PWM carrier
frequency
2.0k to 4.0kHz
4.1k to 12.0kHz
VFS15-6015P
40°C or less
2.7 A
Above 40 to 50°C
2.7 A
VFS15-6022P
40°C or less
3.9 A
Above 40 to 50°C
3.9 A
VFS15-6037P
40°C or less
6.1 A
Above 40 to 50°C
6.1 A
VFS15-6055P
40°C or less
9.0 A
Above 40 to 50°C
9.0 A
VFS15-6075P
40°C or less
11.0 A
Above 40 to 50°C
11.0 A
VFS15-6110P
40°C or less
17.0 A
Above 40 to 50°C
17.0 A
VFS15-6150P
40°C or less
22.0 A
Above 40 to 50°C
22.0 A
Note ) For "Above 40°C to 50°C" of the ambient temperature, remove the protective label on the top of the inverter for
the compliance with UL standard.
Note ) Be sure to connect a line inductance, refer to Table 4 for the value.
VF-S15_QS.indb 39VF-S15_QS.indb 39 2021/11/18 15:51:512021/11/18 15:51:51
VF-S15_QS_CC2021.indd 39VF-S15_QS_CC2021.indd 39 2021/11/18 15:55:262021/11/18 15:55:26

Toshiba Tosvert VF-S15 Specifications

General

Category	Inverter
Control Method	V/f control, Sensorless vector control
Cooling Method	Forced air cooling
Model	Tosvert VF-S15
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheat
Communication Options	Modbus RTU
Overload Capacity	150% for 1 minute
Braking Unit	Built-in braking transistor
Output Voltage	3-Phase, same as input voltage
Operating Temperature	-10 to +50°C (14 to 122°F)
Storage Temperature	-20 to 65°C (-4 to 149°F)
Humidity	5 to 95% RH (non-condensing)
Altitude	Up to 1000m above sea level
Input Voltage	3-Phase 200 to 240 VAC, 3-Phase 380 to 480 VAC
Weight	Varies depending on model (e.g., 0.8 kg to 16 kg)
