Toshiba Tosvert VF-S15 Quick Start Manual

Published in 11/2021
E6581928e
NOTICE
1. Make sure that this instruction manual is delivered to the
end user of the inverter unit.
2. Read this manual before installing or operating the inverter
unit, and store it in a safe place for reference.
Quick Start Manual
Schnellstartanleitung
Guida rapida all’avvio
Manual de inicio rápido
3-phase 240V class 0.4 to 15kW
1-phase 240V class 0.2 to 2.2kW
3-phase 500V class 0.4 to 15kW
Industrial Inverter
(For 3-phase induction motors)
with Safety function
VF-S15_QS_H1-H4.indd 4VF-S15_QS_H1-H4.indd 4 2021/11/18 15:59:202021/11/18 15:59:20
Español
Italiano
Deutsch
English
Published in 11/2021
E6581928e
NOTICE
1. Make sure that this instruction manual is delivered to the
end user of the inverter unit.
2. Read this manual before installing or operating the inverter
unit, and store it in a safe place for reference.
Quick Start Manual
Schnellstartanleitung
Guida rapida all’avvio
Manual de inicio rápido
3-phase 240V class 0.4 to 15kW
1-phase 240V class 0.2 to 2.2kW
3-phase 500V class 0.4 to 15kW
Industrial Inverter
(For 3-phase induction motors)
with Safety function
VF-S15_QS_H1-H4.indd 1VF-S15_QS_H1-H4.indd 1 2021/11/18 15:59:212021/11/18 15:59:21
VF-S15_QS_Cover.indd 4VF-S15_QS_Cover.indd 4 2021/11/18 16:00:132021/11/18 16:00:13

Toshiba Tosvert VF-S15 Specifications

General

Category	Inverter
Control Method	V/f control, Sensorless vector control
Cooling Method	Forced air cooling
Model	Tosvert VF-S15
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheat
Communication Options	Modbus RTU
Overload Capacity	150% for 1 minute
Braking Unit	Built-in braking transistor
Output Voltage	3-Phase, same as input voltage
Operating Temperature	-10 to +50°C (14 to 122°F)
Storage Temperature	-20 to 65°C (-4 to 149°F)
Humidity	5 to 95% RH (non-condensing)
Altitude	Up to 1000m above sea level
Input Voltage	3-Phase 200 to 240 VAC, 3-Phase 380 to 480 VAC
Weight	Varies depending on model (e.g., 0.8 kg to 16 kg)
