E6581611
A-6
1
1.3.2 Opening terminal cover and terminal block
Warning
Prohibited
 Never touch the internal connector while the upper cover of control panel is opened.
There is a risk of electrical shock because it carries a high voltage.
Caution
Mandatory
action
 When removing and mounting the terminal cover or the terminal block with a screwdriver, be sure not
to scratch your hand as these results in injury.
 Pressing too hard on the screwdriver can scratch the inverter.
 Always turn the power off when removing the wiring cover.
 After wiring is complete, be sure to replace the terminal cover.
Use the following procedure to open the terminal cover and pull the power terminal block.
Inverter type Procedure
Reference
number
VFS15-2004PM-W to 2007PM-W
VFS15S-2002PL-W to 2007PL-W
In the beginning, remove the outside terminal
block cover.
(1)
Next, remove the inside terminal block cover. (2)
VFS15-2015PM-W to 2037PM-W
VFS15S-2015PL-W, 2022PL-W
VFS15-4004PL-W to 4015PL-W
In the beginning, remove the outside terminal
block cover.
(3)
Next, remove the inside terminal block cover. (4)
VFS15-4022PL-W, 4037PL-W
In the beginning, remove the outside terminal
block cover.
(3)
Next, remove the inside terminal block cover. (5)
VFS15-2055PM-W to 2150PM-W
VFS15-4055PL-W to 4150PL-W
Follow a procedure and remove the power
terminal cover.
(6)
