E6581611
F-119
6
6.32 Analog input terminal function selection
f214 : VIB input point 1 rate
f215 : VIB input point 2 rate
f663 : Analog input terminal function selection (VIB)
Function
Parameter is normally set from operation panel. However some parameters can be continuously
set from
external
analog input by using this function. VIB terminal is used.
[Parameter setting]
Title Function Adjustment range Default setting
f214
VIB input point 1 rate -250-+250 (%) 0
f215
VIB input point 2 rate -250-+250 (%) 100
f663
Analog input terminal function
selection (VIB)
0: Frequency command
1: Acceleration/deceleration time
2: Upper limit frequency
3, 4: -
5: Torque boost value
6: Stall prevention level
7: Motor electronic-thermal protection level
8 to 10: -
11: Base frequency voltage
0
● Analog input terminal function assigns VIB terminal. The range of analog input voltage is 0% to +100%.
From -100% to 0% cannot be used.
● The parameter that is selected by
f663 can be adjusted range as following table.
Setting of f663 Object parameter VIB : 0% input VIB : 100% input
0: Frequency
command
- - -
1: Acceleration/
deceleration time
acc, dec, f500,
f501, f510, f511
Parameter setting value x
f214
Parameter setting value x
f215
2: Upper limit
frequency
ul
Parameter setting value x
f214
Parameter setting value x
f215
5: Torque boost
value
vb, f172
Parameter setting value x
f214
Parameter setting value x
f215
6: Stall prevention
level
f185, f601
Parameter setting value x
f214
Parameter setting value x
f215
7: Motor electronic-
thermal protection
level
thr, f173
Parameter setting value x
f214
Parameter setting value x
f215
11: Base frequency
voltage
vlv, f171
Parameter setting value x
f214
Parameter setting value x
f215
Note: Adjustments are made by the inverter itself, so no changes are made to parameter settings
