Toshiba TOSVERT VFS15-4075PL-W User Manual

E6581611
F-72
6
[f307=0: No voltage compensation/output voltage limited] [f307=1: Voltage compensation/output voltage limited]
>1 the output voltage can be prevented
from exceeding the input voltage.
 
Rated voltage
* The above is applied when V/F control mode selection
parameter  is set to "0" or "1".
Output voltage
[Ｖ]
Input voltage
Output frequency

High
Low
0
Input voltage

[f307=2: No voltage compensation/no output voltage limit] [f307=3: Voltage compensation/no output voltage control]
Input voltage
High
Low
Output
fre
q
uenc
y
Output voltage
[
V
]
 
0
Input voltage
* The above is applied when V/F control mode selection
param eter  is set to "" or "".
>1 the output voltage can be prevented
from exceeding the input voltage.
 
Rated voltage
Note: Rated voltage is fixed at 200V for 240V class and 400V for 500V class.

Input voltage
High
Low
Output voltage
[V]
Output frequency

0
* Note that even if the input voltage is set less than
, an output voltage over  occurs for a
base frequency of  or higher output frequency.
Input voltage
High
Low
Output voltage
[V]
Output
frequenc
y
 
0

