E6581611
K-9
11
Title
Communication
No.
Function Unit
Minimum
setting unit
Panel/Commun
ication
Adjustment range
Default
setting
User
setting
Reference

0260 Jog run frequency Hz 0.1/0.01
－20.0
5.0 6.14

0261 Jog run stopping
pattern
- - 0: Deceleration stop
1: Coast stop
2: DC braking stop
0

0262 Panel jog run
operation mode
- - 0: Invalid
1: Valid
0

0264 External logic
input - UP
response time
s 0.1/0.1 0.0-10.0 0.1 6.10.4

0265 External logic
input - UP
frequency steps
Hz 0.1/0.01 0.0- 0.1

0266 External logic
input - DOWN
response time
s 0.1/0.1 0.0-10.0 0.1

0267 External logic
input - DOWN
frequency steps
Hz 0.1/0.01 0.0- 0.1

0268 Initial value of
UP/DOWN
frequency
Hz 0.1/0.01

0.0

0269 Change of the
initial value of
UP/DOWN
frequency
- - 0: Not changed
1: Setting of  changed when
power is turned off
1

0270 Jump frequency 1 Hz 0.1/0.01 0.0- 0.0 6.15

0271 Jumping width 1 Hz 0.1/0.01 0.0-30.0 0.0

0272 Jump frequency 2 Hz 0.1/0.01 0.0- 0.0

0273 Jumping width 2 Hz 0.1/0.01 0.0-30.0 0.0

0274 Jump frequency 3 Hz 0.1/0.01 0.0- 0.0

0275 Jumping width 3 Hz 0.1/0.01 0.0-30.0 0.0

0287 Preset-speed
frequency 8
Hz 0.1/0.01 - 0.0 5.7

0288 Preset-speed
frequency 9
Hz 0.1/0.01 - 0.0

0289 Preset-speed
frequency 10
Hz 0.1/0.01 - 0.0

0290 Preset-speed
frequency 11
Hz 0.1/0.01 - 0.0

0291 Preset-speed
frequency 12
Hz 0.1/0.01 - 0.0

0292 Preset-speed
frequency 13
Hz 0.1/0.01 - 0.0

0293 Preset-speed
frequency 14
Hz 0.1/0.01 - 0.0

0294 Preset-speed
frequency 15
Hz 0.1/0.01 - 0.0 5.7
6.30

0295 Bumpless
operation selection
- - 0: Disabled
1: Enabled
0 6.16

0297 Low voltage
operation upper
limit frequency
Hz 0.1/0.01 0.0: Disabled
0.1-30.0
0.0 6.17

0298 Low voltage
operation DC
voltage
Vdc 1/0.1 240V class: 72(96)-168 *11
500V class: 72(120)-336 *11
120
*3: Factory specific coefficient parameters are manufacturer setting parameters. Do not change the value of these parameters.
*11: 240V class : 4.0kW or less : 72 to 168V, 5.5kW or more : 96 to 168V.
500V class : 4.0kW or less : 72 to 336V, 5.5kW or more : 120 to 336V.
