E6581611
K-36
11
 Table of output terminal functions 3
Function
No.
Code Function Action Reference
92 DATA1 Designated data output 1 ON: bit0 of FA50 is ON
OFF: bit0 of FA50 is OFF
6.38
93 DATA1N Inversion of designated data output 1 Inversion of DATA1
94 DATA2 Designated data output 2 ON: bit1 of FA50 is ON
OFF: bit1 of FA50 is OFF
95 DATA2N Inversion of designated data output 2 Inversion of DATA2
106 LLD Light load output ON: Less than heavy load torque (f335~f338)
OFF: heavy load torque (f335~f338) or more
6.21
107 LLDN Inversion of light load output Inversion of LLD
108 HLD Heavy load output ON: Heavy load torque (f335~f338) or more
OFF: Less than heavy load torque (f335~f338)
109 HLDN
Inversion of
heavy load output
Inversion of HLD
120 LLS Lower limit frequency stop ON: Lower limit frequency continuous operation
OFF: Other than those above
6.13
121 LLSN Inversion of lower limit frequency stop Inversion of LLS
122 KEB Power failure synchronized operation ON: Power failure synchronized operation
OFF: Other than those above
6.19.2
123 KEBN Inversion of power failure synchronized
operation
Inversion of KEB
124 TVS Traverse in progress ON: Traverse in progress
OFF: Other than those above
6.40
125 TVSN Inversion of traverse in progress Inversion of TVS
126 TVSD Traverse deceleration in progress ON: Traverse deceleration in progress
OFF: Other than those above
127 TVSDN Inversion of traverse deceleration in
progress
Inversion of TVSD
128 LTA Parts replacement alarm ON: Any one of cooling fan, control board capacitor, or main
circuit capacitor reaches parts replacement time
OFF: Any one of cooling fan, control board capacitor, or main
circuit capacitor does not reach parts replacement time
6.29.15
129 LTAN Inversion of parts replacement alarm Inversion of LTA
130 POT Over-torque detection pre-alarm ON: Torque current is 70% of f616 setting value or more
OFF: Torque current is less than f616x70%-f619
6.29.10
131 POTN Inversion of over-torque detection pre-alarm Inversion of POT
132 FMOD Frequency setting mode selection 1/2 ON: Select frequency setting mode selection 2 (f207)
OFF: Select frequency setting mode selection 1 (fmod)
5.8
133 FMODN Inversion of frequency setting mode
selection 1/2
Inversion of FMOD
136 FLC Panel / remote selection ON: Operation command or panel
OFF: Other than those above
6.2.1
137 FLCN Inversion of panel / remote selection Inversion of FLC
138 FORCE Forced continuous operation in progress ON: Forced continuous operation in progress
OFF: Other than those above
6.30
139 FORCEN Inversion of forced continuous operation in
progress
Inversion of FORCE
140 FIRE Specified frequency operation in progress ON: Specified Frequency operation in progress
OFF: Other than those above
141 FIREN Inversion of specified frequency operation in
progress
Inversion of FIRE
