E6581611
M-4
13
(Continued)
Error code Failure code Problem Possible causes Remedies




0028
0054
0055
0056
Auto-tuning error
 The motor parameter , , ,
,  are not set correctly.
 Set the left column parameters correctly
as a motor name plate and make an auto-
tuning again.
 Set parameter f416 to smaller 70% of
the present value, and execute the auto-
tuning again.
 The motor with the capacity of 2 classes
or less than the inverter is used.
 The output cable is too thin.
 The inverter is used for loads other than
those of three-phase induction motors.
 Set the left column parameters correctly
as a motor name plate and make an auto-
tuning again.
 Then set f400=1, when trip occurs.
 The motor is not connected.  Connect the motor.
 Check whether the secondary magnetic
contactor.
 The motor is rotating.  Make an auto-tuning again after the
rotation of the motor stops.
 Parameter pt=6 is set and High speed
motor is connected.
 Choose the higher power range drive.
(1 class up drive is recommended.)

0022 Ground fault
 A ground fault occurs in the output cable
or the motor.
 Check the cable and the motor for ground
faults.
 Overcurrent of dynamic braking resistor  Increase the deceleration time dec.
 Set the supply voltage correction f307
to 1 or 3.
 When inverters are fed by AC power
supply and connected with common DC
bus link, unnecessary trip occurs.
 Set the parameter f614 to 0
“Disabled”.
*

002F Step-out (for PM
motor drive only)
 The motor shaft is locked.
 One output phase is open.
 An impact load is applied.
 Using the DC braking function.
 Unlock the motor shaft.
 Check the interconnect cables between
the inverter and the motor.
 Prolong the acceleration / deceleration
time.
 Turn off the Step-out function when using
the DC braking function or change the DC
braking to Servo lock function.

0029 Inverter type error
 It may be a breakdown failure.  Contact your Toshiba distributor.

002D Over speed fault
 The input voltage fluctuates abnormally.
 Over speed fault due to the overvoltage
limit operation.
 Check the input voltage.
 Install an optional dynamic braking
resistor. (optional)
*

0032 Analog input break
detection fault
 The input signal from VIC is equal to or
less than the  setting.
 Check the VIC signal cable for breaks.
Also, check the input signal value or
setting of .

0033 CPU communications
error
 A communications error occurs between
control CPUs.
 Contact your Toshiba distributor.

0034 Over torque boost
fault
 The automatic torque boost parameter
 setting is too high.
 The motor has too small impedance.
 Set a lower automatic torque boost
parameter  setting.
 Make an auto-tuning.

0035 CPU fault 2
 The control CPU is defective.  Contact your Toshiba distributor.

0037 Optional unit fault 2
 An optional device is defective.  Contact your Toshiba distributor.

003A CPU fault 3
 The control CPU is defective.  Contact your Toshiba distributor.

0057 Internal circuit fault
 Internal circuit is defective.  Contact your Toshiba distributor.

0063 Heavy cycle of main
power ON/OFF
 Main power ON/OFF during running is
repeated frequently.
 Initial failure if it is caused by other
reasons.
 Reduce the frequency of repetition of
main power ON/OFF during running.
 Contact your Toshiba distributor.

0040 PTC fault
 PTC thermal protection is occurred.  Check the PTC in motor.

0045 Servo lock fault
 The motor shaft is not locked in servo lock
operation.
 Reduce the load in servo lock operation.
* This marking trips can be selected valid or invalid by parameters.
(Continued overleaf)
