Toshiba TOSVERT VFS15-4075PL-W User Manual

E6581611
C-3
3
 Values set by each setup parameter
Title Function
eu
(Mainly in
Europe)
usa
(Mainly in
North America)
asia
(Mainly in Asia,
Oceania)
Note 1)

(Mainly in
Japan)
ul/vl/170/
f204 /f213 /
f219 /f330 /
f367 /f814
Frequency
50.0(Hz) 60.0(Hz) 50.0(Hz)
60.0(Hz)
vlv/
f171
Base
frequency
voltage
1, 2
240V
class
230(V) 230(V) 230(V) 200(V)
500V
class
400(V) 460(V) 400(V)
400(V)
pt
V/F control mode
selection
0 0 0
2
f307
Supply voltage
correction
(output voltage
limitation)
2 2 2 3
f319
Regenerative over-
excitation upper
limit
120 120 120 140
f417 Motor rated speed
1410(min
-1
) 1710(min
-1
) 1410(min
-1
) 1710(min
-1
)
Note 1) Excludes Japan.
Note 2) Slide switch SW1 is set to PLC side at default setting. Set it appropriately according to the logic used.
Refer to page B-11 to 13 for details.
