E6581611
D-11
4
60 Hz default setting (typ=2)
Setting typ to 2 sets the following parameters for base frequency 60 Hz use.
(The setting values of other parameters are not changed.)
• Maximum frequency (fh) : 60Hz • Upper limit frequency (ul) : 60Hz
• Base frequency 1 (vl) : 60Hz • Base frequency 2 (f170) : 60Hz
• VIA input point 2 frequency (f204) : 60Hz • VIB input point 2 frequency (f213) : 60Hz
• VIC input point 2 frequency (f219) : 60Hz • Automatic light-load high-speed operation
• Process upper limit (f367) : 60Hz frequency (f330) : 60Hz
• Motor rated speed (f417) : 1710 min
-
• Communication command point 2 frequency
(f814) : 60Hz
Default setting 1 (typ = 3)
Setting typ to 3 will return parameters to the default settings (exclusive of some parameters).
● When 3 is set, init is displayed for a short time after the settings are configured, and then
disappears. Then the inverter is in standard motor mode. In this case, the trip history data is cleared.
Trip record clear (typ = 4)
Setting typ to 4 initializes the past eight sets of recorded error history data.
● The parameter does not change.
Cumulative operation time clear (typ = 5)
Setting typ to 5 resets the cumulative operation time to the initial value (zero).
Initialization of type information (typ = 6)
Setting typ to 6 clears the trips when an etyp format error occurs. But if the displayed, contact
your Toshiba distributor.
Be aware that the following parameters do not return to the default settings even if typ=3 is set for
maintainability. (To initialize all parameters, set typ=13)
•aul：Overload characteristic selection •f470~f475：VIA/VIB/VIC input bias / gain
•fmsl：Meter selection •f669：Logic output/pulse train output selection
•fm：Meter adjustment gain •f681：Analog output signal selection
•set：Checking the region setting •f691：Inclination characteristic of analog output
•f107：Analog input terminal selection •f692：Analog output bias
• f109：Analog/logic input selection (VIA/VIB) •f880：Free notes
* Refer to “Communication manual” about parameter cxxx.
