Toslon TF520 - Specifications and Features

12
Specifications and Features
Display size: 4.3"TFT LCD; Sunlight Viewable
Resolution: 480*272Pixels; 65,536 color
Language: Multi-language
Monitor and Display Real-time Voltage of Bait boat Battery
IPX6 Level Waterproof Casing Design
Depth Capability: 30m (100ft)
Sonar Frequency: 115Khz
Sonar Beam Angle: 60deg @-10db
Sonar Alarms: Fish / Shallow / Low Battery
Radio Frequency: 2.4Ghz
RC Power: 20dBm
DC 9~15V / 3S lithium battery
Battery: 3S 18650 (Optional)
Sensor Cable Length: 0.5m
Sonar unit size: 153 x110 x 44mm; Portable Case Size: 262 x 150 x 98mm
Operational Temperature: -10°C ~ 50°C
Water Temp. Included in Transducer
Frequency-hopping spread spectrum (FHSS)
Direct-sequence spread spectrum (DSSS)
Hardware gain adjustable
Built in 3S lithium battery charging function
Stable wireless performance even in bad condition
Full two-year warranty; extended warranties avaiable
Display
Sonar
R/F
Power
Features
Technical and
casing
Specications and features
*
*Note:
[1] Not available with TF520 version B, which with a power-adjustable radio system.
[2] For version B, please ensure the TX power compliant with local radio regulations before increasing the radio power.
