21
Installing the Power Cord Hooks
Attach the two power cord hooks on the back of the unit using the included screws
and wrap the power cord around the power cord hooks when not in use.
2. Screw the drain hose adapter into the spout by twisting clockwise and attach the
drain hose to the drain adapter.
Note: When using the continuous drainage option make sure that the air
conditioner is located on a flat, level surface and that the drain hose is directed
downwards and clear of any obstructions. Placing the air conditioner on an uneven
surface may result in the chassis filling with water until the H8 malfunction code is
displayed. If this occurs, manually empty the water in the chassis then recheck the
air conditioner location and hose connection.
Direction of wire hook is upward
Direction of wire hook is downward
Screw
Wire hook
To Next Page
