12
Window Requirements
The instructions outlined below are for standard, vertical-sliding windows. If you have
a different window type (e.g. horizontal-sliding window) you may need to choose a
different window or use a different installation procedure.
If you are installing this air conditioner in a smaller window, you may not need the
accordion subassembly. Please refer to the window size requirements for more details.
In some cases, you may need to put a small wooden block under the air conditioner
to ensure that the unit is not tilting towards the inside of your home. If the unit is tilted
towards the inside of your home, water may drain into your home and damage the
window frame, wall, or flooring. A slight angle of 5° is all it takes to ensure that water
does not drain into your home.
13.5”min
25
”
to 36
”
8,000 BTU minimum width: 25’’
8,000 BTU maximum width: 36”
8,000 BTU minimum height: 13.5”
Installation Procedure
Step 1: Install the top mounting rail
1. Remove the adhesive from the top mounting rail seal strip. Align strip to the four (4)
holes and stick to the side of the mounting rail which attaches to your air conditioner.
