21
black
N(1) 2 3
Outdoor unit connection
green
(yellow-
green)
white
(blue)
red
(brown)
outlet pipe
drain hose
Connect the Piping
4
Connect the Wiring
3
Wrap the Pipping
6
Connect the Drain Hose
5
Mount the Indoor Unit
8
Drill Wall Hole
7
Indoor outdoor
5-10°
