Technical Information
Service Manual
Model TW09HQ3D6D
Product Code CB460005700_L71081
Power Supply
Rated Voltage V~ 208/230
Rated Frequency Hz 50/60
Phases 1
Power Supply Mode Outdoor
Cooling Capacity Btu/h 9000
Heating Capacity Btu/h 9000
Cooling Power Input W 540
Heating Power Input W 610
Cooling Power Current A 3.05
Heating Power Current A 3.15
Rated Input W 1500
Rated Current A 6.2
Air Flow Volume(SH/H/MH/M/ML/L/SL) CFM 424/383/353/324/294/265/206
Dehumidifying Volume Pint/h 1.69
EER (Btu/h)/W 16.67
COP (Btu/h)/W 14.75
SEER 30.5
HSPF 14
Application Area yd
2
19.1-28.7
Indoor Unit
Model of indoor unit TW09HQ3D6DI
Indoor Unit Product Code CB460N05700_L71081
Fan Type Cross-ow
Diameter Length(DXL) inch Φ4 1/6X27 4/5
Fan Motor Cooling Speed (SH/H/MH/M/ML/L/SL) r/min 1250/1170/1100/1020/960/650/600
Fan Motor Heating Speed (SH/H/MH/M/ML/L/SL) r/min 1300/1200/1120/1040/960/880/800
Output of Fan Motor W 60
Fan Motor RLA A 0.09
Fan Motor Capacitor μF /
Evaporator Form Aluminum Fin-copper Tube
Pipe Diameter inch Φ 9/32
Row-n Gap inch 2-1/16
Coil Length (LXDXW) inch 28 9/64X1X12
Swing Motor Model MP35CJ/MP24HF
Output of Swing Motor W 2.5/1.5
Fuse A 3.15
Sound Pressure Level (SH/H/MH/M/ML/L/SL) dB (A) 46/40/38/36/33/31/19
Sound Power Level (SH/H/MH/M/ML/L/SL) dB (A) 56/50/48/46/43/41/29
Dimension (WXHXD) inch 38 13/64X11 13/16X8 5/6
Dimension of Carton Box (LXWXH) inch 40 55/64X15X12
Dimension of Package (LXWXH) inch 41X15X12 39/64
Net Weight Ib 29.8
Gross Weight Ib 36.4
2. Specications
2.1 Specication Sheet
