58
Installation and Maintenance
Service Manual
Above data is subject to change without notice.
No.
Description
Part Code
Qty
TW09HQ3D6DO
Product Code CB497W00200_L71081
1 Front Grill 01473065 1
2 Cabinet 0143303402P 1
3 Axial Flow Fan 10333022 1
4 Fan Motor 1501308507 1
5 Clapboard 01233510 1
6 Chassis Sub-assy 0280311901P 1
7 Electrical Heater (Chassis) 76510004 1
8 Compressor and Fittings 00103977 1
9 Valve Support Sub-Assy 01703242P 1
10 Right Side Plate 0130510002P 1
11 Valve Cover 22243005 1
12 Cable Cross Plate 1 02123013P 1
13 Cable Cross Plate 2 02123014P 1
14 Cut off Valve Sub-Assy 030057000180 1
15 Cut off Valve 1/2 0710307901 1
16 4-Way Valve Assy 03073360 1
17 Magnet Coil 4300008301 1
18 Capillary Sub-assy 030006060038 1
19 Wiring Clamp 26115004 1
20 Condenser Assy 011002060037 1
21 Rear Grill 0147306001 1
22 Electric Expand Valve Fitting 4300876704 1
23 Stationary Barrier 01703179 1
24 Electronic Expansion Valve 07133909 1
25 Flash Vaporizer Sub-assy 07223057 1
26 Magnet Coil 4300008301 1
27 Tube Clip 02143030 1
28 Reactor 43130185 1
29 Coping 012049000006P 1
30 Motor Support Sub-Assy 01703180 1
31 Left Side Plate 01303169P 1
32 Electric Box Assy 100002060314 1
33 Electric Box Cover Sub-Assy 0260309601 1
34 Main Board 300027060051 1
35 Electric Box 1 20113005 1
36 Terminal Board 42010313 1
37 Wire Clamp 71010003 2
38 Temperature Sensor 39000079 1
To Next Page
