Tosot TW09HQ3D6D User Manual

60
Installation and Maintenance
Service Manual
Loosen the connection clasps between
frontcase sub-assy and bottom case.
Bottom case
Lift up the
front case sub-assy and take
Swingmotor
Screw off the screws that are locking
theswing motor and take the motor off.
it out.
4. Remove detecting plate and electric box cover2
Remove the screws fixing detecting plate
and remove detecting plate.
Remove the screws fixing electric box
cober2 and remove electric box2.
Detecting plate
2

Tosot TW09HQ3D6D Specifications

General

Brand	Tosot
Model	TW09HQ3D6D
Category	Air Conditioner
Language	English
