Total Control Systems 700-20 - Gear Plate Information

- 38 -
GEAR PLATE INFORMATION
TCS STANDARD
Meter
Packing
Gear
Units
Registration
Type
Shafts
Ratio:1
Inverse
Ratio
Rotation
Verification Test
Tenths
Reading
Whole
Reading
Gears
GEAR PLATES
VR
310450-237
700-15
4:1
US Gallons
1/10
7
Single
0.766
1.305
CCW
Rotate LEFT one (1) time
1.3
13.1
64-48-49
VR
324823-214
700-15
4:1
US Gallons - Preset
1/10
7
Double
0.766
1.305
CCW
Rotate LEFT one (1) time
1.3
13.1
64-48-49
VR
310450-524
700-15
4:1
US Gallons
Whole
5
Single
7.655
0.131
CCW
Rotate RIGHT one (1) time
0.1
1.3
35-69-35-69-33-33-65
VR
324823-510
700-15
4:1
US Gallons - Preset
Whole
5
Double
7.655
0.131
CCW
Rotate RIGHT one (1) time
0.1
1.3
35-69-35-69-33-33-65
VR
70854-260
700-15
4:1
Liters
Whole
7
Single
2.022
0.495
CCW
Rotate LEFT one (1) time
0.5
4.9
34-48-69
VR
324823-213
700-15
4:1
Liters - Preset
Whole
7
Double
2.022
0.495
CCW
Rotate LEFT one (1) time
0.5
4.9
34-48-69
VR
310450-522
700-15
4:1
Imperial Gallons
Whole
5
Single
9.183
0.109
CCW
Rotate LEFT one (1) time
0.1
1.1
28-70-49-80-28-34-63
VR
310450-238
700-20/25
2:1
US Gallons
1/10
7
Single
0.695
1.439
CCW
Rotate LEFT one (1) time
1.4
14.4
59-48-41
VR
324823-215
700-20/25
2:1
US Gallons - Preset
1/10
7
Double
0.695
1.439
CCW
Rotate LEFT one (1) time
1.4
14.4
59-48-41
VR
310450-521
700-20/25
2:1
US Gallons
Whole
5
Single
6.949
0.144
CCW
Rotate LEFT one (1) time
0.1
1.4
29-65-44-62-30-32-66
VR
324823-509
700-20/25
2:1
US Gallons - Preset
Whole
5
Double
6.949
0.144
CCW
Rotate LEFT one (1) time
0.1
1.4
29-65-44-62-30-32-66
VR
310450-523
700-20/25
2:1
Imperial Gallons
Whole
5
Single
8.338
0.120
CCW
Rotate RIGHT one (1) time
0.1
0.0
34-63-33-66-28-34-63
VR
310450-233
700-20/25
2:1
Liters
Whole
7
Single
1.836
0.545
CCW
Rotate LEFT one (1) time
0.5
5.4
31-46-57
VR
324823-204
700-20/25
2:1
Liters - Preset
Whole
7
Double
1.836
0.545
CCW
Rotate LEFT one (1) time
0.5
5.4
31-46-57
VR
310450-746
700-30/35
2:1
US Gallons
Whole
6
Single
2.575
0.388
CCW
Rotate LEFT one (1) time
0.4
3.9
43-69-43-69
VR
324823-712
700-30/35
2:1
US Gallons - Preset
Whole
6
Double
2.575
0.388
CCW
Rotate LEFT one (1) time
0.4
3.9
43-69-43-69
VR
310450-759
700-30/35
1:1
US Gallons
1/10
6
Single
0.515
1.942
CCW
Rotate RIGHT one (1) time
1.9
19.4
66-33-67-69
VR
310450-752
700-30/35
1:1
US Gallons - Preset
1/10
6
Double
0.515
1.942
CCW
Rotate RIGHT one (1) time
1.9
19.4
66-33-67-69
VR
310450-750
700-30/35
2:1
Imperial Gallons
Whole
6
Single
3.089
0.324
CCW
Rotate LEFT one (1) time
0.3
3.2
33-58-33-58
VR
326253-705
700-30/35
2:1
Liters
Whole
6
Single
0.680
1.470
CCW
Rotate LEFT one (1) time
1.5
14.7
50-68-64-32
VR
324823-711
700-30/35
2:1
Liters - Preset
Whole
6
Double
0.680
1.470
CCW
Rotate LEFT one (1) time
1.5
14.7
50-68-64-32
VR
326253-200
700-40/45
2:1
Dekaliter
Whole
7
Single
2.452
0.408
CCW
Rotate LEFT one (1) time
0.4
4.1
32-42-78
VR
324823-211
700-40/45
2:1
Dekaliter - Preset
Whole
7
Double
2.452
0.408
CCW
Rotate LEFT one (1) time
0.4
4.1
32-42-78
VR
310450-747
700-40/45
2:1
US Gallons
Whole
6
Single
0.929
1.076
CCW
Rotate LEFT one (1) time
1.1
10.8
54-49-43-44
VR
324823-713
700-40/45
2:1
US Gallons - Preset
Whole
6
Double
0.929
1.076
CCW
Rotate LEFT one (1) time
1.1
10.8
54-49-43-44
VR
310450-751
700-40/45
2:1
Imperial Gallons
Whole
6
Single
1.114
0.898
CCW
Rotate LEFT one (1) time
0.9
9.0
66-42-28-49
VR
326253-704
700-40/45
2:1
Liters
Whole
6
Single
0.245
4.078
CCW
Rotate LEFT one (1) time
4.1
40.8
57-28-60-30
VR
324823-710
700-40/45
2:1
Liters - Preset
Whole
6
Double
0.245
4.078
CCW
Rotate LEFT one (1) time
4.1
40.8
57-28-60-30
