ELITE PLUS OWNER’S MANUAL | PRODUCT SPECIFICATIONS
4 To order optional accessories, please go to TotalGymDirect.com 4
Product Specications
Pulley/Cable Assembly
WARNING
LABEL 2
WARNING
LABEL 3
WARNING
LABEL 4
WARNING
LABEL 4
CAUTION
LABEL 1
WARNING
LABEL 6
WARNING
LABEL 1
Height Adjustment Slide Mechanism
Spring Loaded Pin
(Located on Left Side of Rail)
Handle
Top Inner Rail
Safety Pin
Attached
to Lanyard
Vertical Column
Safety Hitch C Pin
Back Crossbar
Tube Roller
Center Support Rail
Glideboard Hook
Attaches Pulley/Cable Hook under Glideboard
Glideboard
Bottom Outer Rail
Tube Cap
Items shown below are packed in
Miscellaneous Accessories
4 Short Hitch Pins
used with AbCrunch and Press
Up / Pull Up Bar Accessories
LENGTH
Folded ................................. 50.5”
In Use .................................... 93”
HEIGHT
Folded ...................................... 8”
In Use ............................... 43.25”
Width .................................. 15.5”
Weight ........................... 53.2 lbs.
Maximum User Weight ..... 300 lbs.
LABEL LOCATIONS AND PARTS IDENTIFIER
Total Gym
®
Elite Plus includes 4 Workout DVDs
PRESS UP / PULL UP BARS
(OPTIONAL)
Safety Hitch C Pin
ABCRUNCH
(OPTIONAL)
10mm & 13mm
Hex Wrench
CAUTION
LABEL 2
CAUTION
LABEL 3
LEG PULL ACCESSORY / PILATES KIT (OPTIONAL)
Pulley/D-Ring Assembly
Ankle Cuffs
Pilates Toe Bar
24-Inch Leg Pulley
Extension Rope
CAUTION
LABEL 4
1 Large Hitch Pin
for use with Leg
Pulley Bracket
Leg Pulley Bracket
for use with Leg Pull
Accessory only
WARNING
LABEL 5
Rope
Clip
Leg Pulley Assembly:
Front Crossbar
Fender
®
Cable
Pilates Toe Bar
(Optional)
Receptacle
Flip Chart Base
FLIP CHART
(OPTIONAL)
O-Ring
Pilates Parts:
