| English
12
1. Carter of protection
2. 3-teeth blade
1. Nylon wire
2. Device of cutting the nylon wire
3. Carter of protection
Technical specifications
Engine information.
Type of engine RY1E44F-5, 2-stroke engine
Volume of the fuel tank 1200 cm³
Max engine speed Max. 10000 minˉ¹
Engine idling speed 3100±400 minˉ¹
Clutch engagement speed 4500 minˉ¹
Engine displacement 52 cm³
Maximal power 1.4 kW
Brush cutter
Unit without cutting attachment, empty tank 7,3 kg
Cutting diameter 255 mm
Cutting thickness 1.4 mm
Number of cutting teeth Single piece (three teeth metal blade)
Blade hole centre diameter 25.4
Maximum rotational frequency of the spindle 7500 minˉ¹
Gear ratio 4:3
Engine speed with cutting attachment 10000 minˉ¹
Cutting blade JINLIFU 10000/min
Vibration ahv (front handle)
Vibration ahv (rear handle)
ahveq =7,15m/s2
ahveq =6,83m/s2
Noise Emission Sound pressure: LpA, av = 90.6dB(A)
Sound power: LwA, av = 109.4 dB (A)
