1. Disconnect the UV light from the outlet. Be sure to allow
sufficient time for the light to cool before disassembling the
light.
Fig. 7
Fig. 7
2. Rotate the locking ring counterclockwise to remove the lamp
holder. Fig. 8
Fig. 8
3. Carefully remove the old bulb by firmly pulling on the base.
Carefully install the new bulb. Fig. 9
Fig. 9
4. Reinstall the lamp holder and locking ring. Fig. 10
NOTE: This clarifier has a safety feature that only allows the
UV light to turn on if the lamp holder is fully seated
into the lamp housing.
Fig. 10
Ring
Ring
4
