Toto TSPTM - Rough-In Dimensions; Tub And Shower Installation; Shower Only Installation

20
ROUGH-IN DIMENSIONS / DIMENSIONES PRELIMINARES /
DIMENSIONS BRUTES
12" ± 1”
305 mm
±
25 mm
~4-6" [~102-152"]
~78-82"
[~1920-2080 mm]
~46-52" [~1170-1320 mm]
~78-82" [~1920-2080 mm]
Cap "TUB"
Outlet
Tub Rim
Shower Floor
Tub And Shower Installation
Shower Only Installation
Dashed Pipework and Components Not Included
Dashed Pipework and Components Not Included
Tub Floor
40” or more
1016 mm
or more
12" ± 1”
305 mm
±
25 mm
~4-6" [~102-152"]
~78-82"
[~1920-2080 mm]
~46-52" [~1170-1320 mm]
~78-82" [~1920-2080 mm]
Cap "TUB"
Outlet
Tub Rim
Shower Floor
Tub And Shower Installation
Shower Only Installation
Dashed Pipework and Components Not Included
Dashed Pipework and Components Not Included
Tub Floor
40” or more
1016 mm
or more
