Toto UT104EV - Dimensions Brutes

13
FRANÇAIS
DIMENSIONS BRUTES
2-1/2" (61mm)
12-1/4"
(310mm)
17" (ADA)
(432mm)
24"
(610mm)
3/4"
(19mm)
Spud
Sortie
Mur Fini
Plancher Fini
2"
(51mm)
I.P.
Intérieur
Filetage
Joint
Brides de sortie
4-1/4"
(108mm)
Détails de sortie
14"
(356mm)
C/L
3/4" (19mm) Alimentation I.P.S
du robinet de chasse
21-1/4"
(540mm)
11-1/2"
(292mm)
10-3/8"
(264mm)
12-1/4"
(310mm)
4-3/4"
(121mm)
4-1/4"
(108mm)
19-1/4"
(490mm)
12-1/4" (ADA)
(311mm)
(51mm)
2”
Sortie
I.P.
Intérieur
Filetage
Junta
6"
(152mm)
Brides de sortie
2-3/8" (61mm)
17-1/2" (445mm)
3/4" (19mm)
12" (305mm)
4 3/4" (121mm)
11 1/2" (292mm)
12 5/8" (320mm)
16 3/4" (424mm)
17 3/4" (451mm)
19 5/8" (500mm)
OU
** 12 5/8” (321mm)
4 3/8" (110mm)
3/4" (19mm) Alimentation
I.P.S du robinet de chasse
2-1/2" (63.5mm)
14-1/4" (362mm)
24" (610mm)
OU
**17” (432mm)
Support de
montage
SPUD
Mur Fini
Plancher Fini
6" (152mm)
