5
ENGLISH
URINAL STRAINER INSTALLATION
VISUAL INSPECTION
Remove part from plastic bag.
Make sure all components are assembled
as shown.
Make sure urinal trapway is dry before
installation.
INSTALLATION INSTRUCTIONS
Place the strainer in the trapway opening.
Orient legs as shown.
Press the unit until the grate fully seats in the china.
Included with UT105U(V)(G) and UT445U(V) only.
Screw
Grate
Hex Nut
To Next Page
