4
ENGLISH
• Turn off water supply and if necessary remove the old urinal.
• Install or relocate the water supply pipe and drain pipe to the specified
rough-in dimensions shown above.
• Install adequate support to mount the urinal.
• Install the wall hanger per rough-in specification.
• Apply sealant tape to the drain pipe threads and install the outlet flange
to the drain pipe, making sure the mounting holes are level.
• Install the gasket on the outlet flange.
• Carefully position the urinal on the wall hanger.
• Secure the urinal to outlet flange with screws and washers.
INSTALLATION PROCEDURE
• Install the flush valve per manufacturer’s instructions.
• Turn-on the water supply and flush urinal several times.
• Carefully check all connections for leaks.
