Introduction
Package Contents
The DA950-U package (TouchTunes P/N 600170-001) contains the following components:
Specifications
• Left channel / Right channel: 125W (RMS), 4 ohms per channel.
• Bridged bass channel: 475W (RMS), total load 4 ohms (3-channel mode).
• Total harmonic distortion: 0.002%.
• Frequency response (all channels): 20Hz- 20KHz, ± 0.15 dB.
• Signal to noise ratio: 96 dB.
• Dynamic Range: 117 dB.
• Input ± 7V RMS balanced.
• Power: 100 to 120 V AC.
• Dimensions: Width=8 3/4” (222mm), Height=2 9/16” (65mm), Depth=13” (331mm).
• Weight: 6.2 lbs (2.8 kg).
Important Safety Instructions
Please read the following important safety instructions before proceeding with product
installation.
Part No. Description Quantity
700720-001 DA950-U amplifier 1
300615-035 AC power cable 1
100000-001 Euroblock connectors (pre-installed
in their sockets on the DA950-U)
3
900701-001 This document 1
The Lightning Flash with arrow head symbol within an equilateral triangle is
intended to alert the user to the presence of un-insulated "dangerous voltage"
within the product enclosure that may be of sufficient magnitude to constitute
a risk of shock to persons".
The exclamation point within an equilateral triangle is intended to alert the user
to the presence of important operating and maintenance (servicing)
instructions in the literature accompanying the product".
