INTRODUCTION
––––––––––––––––––––––––
Thank you for purchasing the Tower Hobbies EP Hellcat. Not
quite as much the “household” name as your Mustangs or Corsairs,
the Hellcat is every bit as impactful when you see it in person—
whether it’s the model or the real thing! But hey, what to say about
this Tower Hobbies Hellcat? There’s not really much to it other
than an economical, durable and simple model with considerable
surface and scale detail and it fl ies great! Get it together, head to
your fl ying site, get it into the air and have fun!
For the latest technical updates or manual corrections to the
Hellcat, visit the Tower Hobbies web site at www.towerhobbies.
com. Open the “Airplanes” link, then select the EP Hellcat ARF.
If there is new technical information or changes to this model a
“tech notice” box will appear in the upper left corner of the page.
AMA
If you are not already a member of the AMA, please join! The
AMA is the governing body of model aviation and membership
provides liability insurance coverage, protects modelers’ rights
and interests and is required to fl y at most R/C sites.
Academy of Model Aeronautics
5151 East Memorial Drive
Muncie, IN 47302-9252
Tele. (800) 435-9262
Fax (765) 741-0057
Or via the Internet at: www.modelaircraft.org
IMPORTANT: Two of the most important things you can do to
preserve the radio controlled aircraft hobby are to avoid fl ying near
full-scale aircraft and avoid fl ying near or over groups of people.
SAFETY PRECAUTIONS
––––––––––––––––
PROTECT YOUR MODEL, YOURSELF & OTHERS…
FOLLOW THESE IMPORTANT SAFETY PRECAUTIONS
1. Your EP Hellcat should not be considered a toy, but rather a
sophisticated, working model that functions very much like a
full-size airplane. Because of its performance capabilities, the
Hellcat, if not assembled and operated correctly, could possibly
cause injury to yourself or spectators and damage to property.
2. You must assemble the Hellcat according to the instructions.
Do not alter or modify the model, as doing so may result in an
unsafe or unfl yable model. In a few cases the instructions may
differ slightly from the photos. In those instances the written
instructions should be considered as correct.
3. You must use an R/C radio system that is in good condition.
All components must be correctly installed so that the model
operates correctly on the ground and in the air. You must check
the operation of the model and all components before every fl ight.
4. If you are not an experienced pilot or have not fl own this type
of model before, we recommend that you get the assistance
of an experienced pilot in your R/C club for your fi rst fl ights.
If you’re not a member of a club, your local hobby shop has
information about clubs in your area whose membership includes
experienced pilots.
5. While this kit has been fl ight tested to exceed normal use, if the
plane will be used for extremely high stress fl ying, such as racing,
or if a motor or battery larger than ones in the recommended range
is used, the modeler is responsible for taking steps to reinforce
the high stress points and/or substituting hardware more suitable
for the increased stress.
We, as the kit manufacturer, provide you with a top quality,
thoroughly tested kit and instructions, but ultimately the
quality and fl yability of your fi nished model depends on how
you build it; therefore, we cannot in any way guarantee the
performance of your completed model, and no representations
are expressed or implied as to the performance or safety of
your completed model.
REMEMBER: Take your time and follow the instructions to
end up with a well-built model.
REQUIRED FOR COMPLETION
–––––––––
No extraordinary tools or building supplies are required to
fi nish the EP Hellcat—just a Phillips screwdriver. The Hellcat
is already equipped with servos, ESC and motor, so the only
other components you have to supply are as follows:
■ Minimum 4-channel transmitter and receiver
■ 3S 11.1V 1800mAh 2200mAh LiPo battery:
Electrifl y 2200mAh 30C (GPMP0681)
FlightPower 2100mAh 25C (FPWP4196)
FlightPower 2200mAh 30C (FPWP6198)
Flyzone 2100mAh 20C (FLZA6173)
(See page 6 for more about batteries.)
■ LiPo battery charger
NOTE: If using a battery with a Deans
®
Ultra Plug
®
connector,
a Deans Ultra Male-to-SuperTigre ESC adapter (SUPM0040)
will also be required (or the connector on the ESC may simply
be replaced with a Deans Ultra Male connector).
