4
MAIN ASSEMBLY
––––––––––––––––––––––
NOTE: If you haven’t yet fi gured it out yet, the canopy hatch
is held to the fuselage with magnets at the rear and a tab at the
front. To remove the hatch, simply lift up on the aft end of the
hatch to disengage the magnets.
❏
1. Fit the horizontal and vertical stabilizer (stab and fi n)
together, then fi t them to the fuselage while keying the tail gear
into the rudder.
❏
2. Fasten the stab and fi n assembly to the fuselage with the
M3 x 40 screw.
❏
3. Connect the pushrods to the horns as shown.
❏
4. Insert one, then the other main landing gear wires into
the wing – the wire struts are positioned inboard of the wheels.
❏
5. Guide the aileron servo wire through the hole in the bot-
tom of the wing.
