LiPo Battery Charger
Most modelers may already have a suitable LiPo charger, but for
those that do not, the Duratrax Onyx 235 AC/DC Advance Peak
Charger (DTXP4235) is one of the suitable chargers recommended.
The Onyx charger is perfect for 3S batteries used with the Hellcat
and may be powered either by an external DC power source
(such as a 12 battery), or a 110V AC outlet. The Onyx also has
an adjustable charge rate to charge your batteries in as little as a
half-hour or less (depending on the condition of your batteries
and the manufacturer’s specifi ed charge rate). The Onyx can also
charge larger batteries and batteries other than LiPos, so it is a
versatile charger you can grow into. The 235 also has an LCD
digital display screen, so you can see how much capacity it took
to recharge the battery (required for monitoring the condition of
your batteries and calculating how long you can fl y).
NOTE: For use with the Onyx 235, LiPo batteries that come
with a SuperTigre connector (such as the Flyzone batteries
recommended) require a banana plugs-to-SuperTigre charge
lead (SUPM0070). And batteries that come with a Deans Ultra
connector require a Charge Lead with banana plugs/Deans Ultra
Male charge lead (GPMM3148).
KIT INSPECTION
–––––––––––––––––––––––
Before assembly, take an inventory of this kit to make sure it is
complete, and inspect the parts to make sure they are of acceptable
quality. If any parts are missing or are not of acceptable quality, or
if you need assistance with assembly, contact Product Support.
When reporting defective or missing parts, use the part names
exactly as they are written in the Kit Contents list.
Hobbico Product Support Ph: (217) 398-8970 ext. 5
3002 N Apollo Drive Suite 1 Fax: (217) 398-7721
Champaign, IL 61822
E-mail: airsupport@hobbico.com
ORDERING REPLACEMENT PARTS
––––
Replacement parts for the Tower Hobbies EP Hellcat are available
using the order numbers in the Replacement Parts List that
follows. The fastest, most economical service can be provided
by your hobby dealer or mail-order company.
To locate a hobby dealer, visit the Hobbico web site at www.
hobbico.com. Choose “Where to Buy” at the bottom of the menu
on the left side of the page. Follow the instructions provided on
the page to locate a U.S., Canadian or International dealer.
Parts may be ordered directly from Hobby Services by calling
(217) 398-0007, or via facsimile at (217) 398-7721, but full retail
prices and shipping and handling charges will apply. Illinois
and Nevada residents will also be charged sales tax. If ordering
via fax, include a Visa
®
or MasterCard
®
number and expiration
date for payment.
Mail parts orders Hobby Services
and payments by 3002 N Apollo Drive, Suite 1
personal check to: Champaign IL 61822
Be certain to specify the order number exactly as listed in the
Replacement Parts List. Payment by credit card or personal
check only; no C.O.D.
If additional assistance is required for any reason contact Product
Support by e-mail at productsupport@hobbico.com, or by
telephone at (217) 398-8970.
Order No. Description
REPLACEMENT PARTS LIST
Wing
Fuselage
Horizontal Stabilizer
Vertical Stabilizer
Cowl
Canopy/Hatch
Wing Bolt ( 2 pcs. )
Landing Gear
10x6 3 Blade Propeller
Tail Gear
Spinner Hub
Servo
30A Brushless ESC
1000kV Outrunner Motor
TOWA6095
TOWA6096
TOWA6097
TOWA6098
TOWA6099
TOWA6100
TOWA6101
TOWA6102
TOWA6103
GPMQ1888
TOWA6092
TOWM5500
SUPM1030
TOWG2000
–––––––––––––––––––––––––––––––––––
CONTENTS
––––––––––––––––––––––––––––––––––––
1. Fuselage, Cowl, Canopy Hatch
2. Wing
3. Vertical Stabilizer
4. Horizontal Stabilizer
5. Hardware Bag
6. Main Landing Gear
7. Propeller Hub
8. Propeller
1
6
2
4
7
8
3
5
