拓陽精密科 TOYAN ENGINE
10
NOTES ON ENGINE START
For personal safety, it is strongly recommended not to disassemble the engine and start-up
mechanism. If you encounter start-up problems, you can contact local distributors or
TOYAN technicians to solve them. If you need to return to the factory for testing, TOYAN
will provide you with high-quality after-sales service. If there is a bad situation caused by
private disassembly, you will bear the corresponding responsibilities and costs.
1. GLOW PLUG(SPARK PLUG):
FS-S100x series requires 1 glowplugs, specially designed for four-stroke methanol engines. With
a glowplug engine, ignition is initiated by the application of a 1.5-volt power source. When the
battery is disconnected, the heat retained within the combustion chamber remains sufficient to
keep the plug filament glowing, thereby continuing to keep the engine running. When the top
dead point of compression is reached, the "automatic" ignition explosion will be realized, while
the electric heat plug remains in a high temperature state, under reduced load, allowing higher
rpm. Conversely, at reduced rpm, the plug becomes cooler. If the speed is too low, the ignition
