拓陽精密科 TOYAN ENGINE
7
BASIC STRUCTURE AND PARTS
spark plug
timing synchronization belt
guide wheel
timing synchronous pulley
camshaft
guide axle
wheel cooling fan fan blade
crankcase chassis oil discharge nozzle

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Toyan Engine FS-S100 Series and is the answer not in the manual?

Toyan Engine FS-S100 Series Specifications

General IconGeneral
Cooling Method/SystemAir-cooled
Lubrication SystemSplash lubrication
Ignition SystemCDI (Capacitor Discharge Ignition)
Engine TypeSingle-cylinder, 4-stroke, air-cooled
Fuel TypeGasoline (90# or higher)
