’05MY CELICA U (L/O 0409)
248
2005 CELICA from Sep. ’04 Prod. (OM20888U)
Good Blown
Type A
Good Blown
Type B
Good Blown
Type C
Good Blown
Type D
If the headlights or other electrical
components do not work, check the
fuses. If any of the fuses are blown,
they must be replaced.
See “Fuse locations” in Section 7−1 for
locations of the fuses.
Turn the ignition switch and inoperative
component off. Pull the suspected fuse
straight out and check it.
Determine which fuse may be causing the
problem. The lid of the fuse box shows
the name of the circuit for each fuse. See
Section 8 for the functions controlled by
each circuit.
Checking and replacing fuses
To Next Page
