Point Operations
[Point I]
Inspection:
Measure the piston rod outside diameter.
Standard: 50.8 mm (2.00 in)
Limit: 50.72 mm (1.9969 in)
Inspection:
Measure the piston rod bend.
Limit: 2.0 mm (0.079 in)
[Point
21
Inspection:
Measure the lift cylinder bore.
Standard: 63.5 mm (2.50 in)
Limit: 63.85 mm (2.5138 in)
