Section 2. Safety Toyota Orderpicker Model 7BPUE 15 Service Manual
Towing a Disabled Unit
Towing a Disabled Unit
To safely tow a Toyota Orderpicker:
1. Lower the operator platform and remove
any load.
2. Turn the key switch OFF and disconnect
the battery connector.
3. Using a suitable towing vehicle, lift the
tractor end of the truck until the drive tire
is no more that
1 inch (25.4 mm) off the
floor.
4. Tow the truck slowly in the tractor - first
direction.
Figure 2-8. Location For Release Bolts In Brake
N O T E : If you must tow the truck flat on the
ground, you must install the brake
release bolts provided. See Figure 2 - 8
and Figure 2
- 9.
Steering is disabled while you are
towing, so you will need to manually
turn the drive unit to steer.
Figure 2-9. Brake Release Bolts
00700 - CL222 - 05, 1 5 March 2005
