Product details
Product guide – BT Levio W-series
25
Product details
Operator environment
The LWE trucks are primarily designed for operators walking alongside the truck
and not standing on a platform, however, the LWE200 can be ordered with optional
platform.
Tiller arm and controls
There are two versions of the tiller arm for the LWE series. One is designed for the
walkie versions while the other is designed for the platform versions with the op-
erator riding onboard. Both versions use BT's ergonomic handles. On the LWE140
and LWE160, the handle is slightly smaller than on the other versions. Main com-
ponents and controls are located as follows:
1. Battery disconnector and charger connector 6. Travel direction selector and speed control
2. Tiller arm and brake 7. Safety reversing switch
3. Emergency switch-off 8. Display
4. Keypad 9. Control for lifting and lowering the forks
5. Horn 10. Creep speed
6+10
7
9
5
8
6+10
4
1
3
2
