3-7 Adjustment of the Jump motor
position
[Inspection]
(1) Remove the needle case.
[『Refer to “ 4-5.Needle bar
reciprocator” 』 on page 41]
(2) Remove three setting screws (a), two
set screws (b) and remove the arm
front cover L. (Fig.1)
(3) In this state, the clearance between
the jump lever and needle bar
3.ADJUSTMENT
Guide pin
B
(b)
Thread presser
(c)
Thread wipe
r
motor base
-32-
Thread wipe
r
hook base
