4-3. Do-it-yourself maintenance

Maintenance and care

iQ_WE_74014E

Checking and replacing fuses

If any of the electrical components do not operate, a fuse may have

blown. If this happens, check and replace the fuses as necessary.

Vehicles without smart entry & start system:

Turn the engine switch to the LOCK position.

Vehicles with smart entry & start system:

Turn the “ENGINE START STOP” switch OFF.

The fuses are located in the following places. To check the

fuses, follow the instructions below.

 Engine compartment

Type A

Remove the cover.

Default Chapter1
- Default Chapter1
