4-3. Do-it-yourself maintenance
4
Maintenance and care
iQ_WE_74014E
*
1
: Vehicles without daytime running light system and automatic light off system
*
2
: Vehicles with daytime running light system or automatic light off system
10
TAIL NO.1
*
1
10 A
Manual headlight leveling dial, front
position lights, tail lights, license
plate lights
(PANEL NO.2) *
2
5 A Daytime running light system
11 DOOR NO.2 20 A Power windows
12 D/L NO.1 15 A
Power door lock system, main body
ECU
13 DOOR NO.1 30 A Power windows
14 CIG 15 A Power outlet
15 ACC 5 A
Outside rear view mirrors, audio
system, shift lock control system,
main body ECU
16
PANEL
*
1
5 A
Meter, power management ECU
(PANEL NO.1) *
2
Meter
17
TAIL NO.2
*
1
10 A
Front position lights, tail lights,
license plate lights, rear fog light,
front fog lights, manual headlight
leveling dial, multiport fuel injection
system/sequential multiport fuel
injection system, instrument clus-
ter, windshield wiper ECU
TAIL
*
2
18 (FOG FR) 15 A Front fog lights
19 AM1 7.5 A ACC, starting system
20 STOP 10 A
Vehicle stability control system,
power management ECU, shift lock
control system, stop lights, multiport
fuel injection system/sequential
multiport fuel injection system
21 (D/L NO.2) 10 A Power door lock system
22 (SEAT-HTR) 15 A Seat heaters
Fuse Ampere Circuit
