TP-Link BE230 - Position Your Router; Connect Your Router

4
Chapter 1 Get to Know About Your Router
1. 1. Product Overview
TP-Link dual band Wi-Fi 7 router, with the 802.11be Wi-Fi technology, achieves Wi-Fi
performance at its ultimate level. The new features of Wi-Fi 7 and 4k QAM dramatically
improve throughput and increase the capacity and efficiency of the whole network.
It is simple and convenient to set up and use the TP-Link router due to its intuitive Tether
app and powerful web interface.
1. 2. Appearance
1. 2. 1. Front Panel
LED Explanation
LED Status Indication
(Power)
On The system has started up successfully.
Flashing
The system is starting up or the firmware is being upgraded. Do
not disconnect or power off your router.
Off Power is off.
(2.4GHz Wireless)
On The 2.4GHz wireless band is enabled.
Off The 2.4GHz wireless band is disabled.
(5GHz Wireless)
On The 5GHz wireless band is enabled.
Off The 5GHz wireless band is disabled.
