4
Attach the EAP to the mounting bracket
by aligning ARROW 1 (on the EAP) with
ARROW 2 (on the mounting bracket), then
rotate the EAP clockwise until it locks into
place.
5
Feed the Ethernet cable through the hole and
set the ceiling tile back into place. Connect
the Ethernet cable to the ETHERNET port.
■
Option3
：
Wall Mounting
Follow the steps below to install the EAP with the provided accessories:
1
Attach the EAP to the mounting bracket by
aligning ARROW 1 (on the EAP) with ARROW
2 (on the mounting bracket), then rotate the
EAP clockwise until it locks into place.
2
Make two small pencil marks on the wall. Make
sure the two marks are level and should be
98.6mm apart. Drill two 6mm holes through
the center of your marks.
98.6mm
M3×28 Plastic Wall Anchors
(Qty.4)
M3×20 Self-tapping Screws
(Qty.4)
To Next Page
