Chapter 1 Introduction
1.1 Overview of the Product
The PSM150-AC is an AC-input and DC-output power supply
module. It can convert the input voltage to 12 Volts with the
maximum output power of 150 Watts. The power supply
module is fully hot swappable, helping to ensure no system
interruption during installation or replacement. PSM150-AC is
applicable to multiple TP-Link switch models.
Power
PS OK
Fault
PSM150-AC
100-240~50/60Hz 2.5A
Figure 1-1 Appearance of PSM150-AC
Power
PS OK
Fault
PSM150-AC
100-240~50/60Hz 2.5A
Fastening Screw AC power input jack
Power supply module handle
Figure 1-2 Front Panel of PSM150-AC
