TP-Link tapo D210 - Install Your Doorbell

6
Install Your Doorbell
Follow the steps below to install your new doorbell.
Required Accessories:
Mounting Bracket 3M Adhesive
Optional
Horizontal
Mounting wedge
Vertical
Mounting wedge
Mounting Wedge
Screws ×4
3M
3M
3M
3M
UP
Attach the wedge’s
grid-side to the bracket.
UP
Option 1. Stick to a smooth wall
1. Attach the included adhesive to the back of the bracket or the
wedge. If you use the wedge to adjust angle, rst ax the bracket
and the wedge with screws.
Note: The adhesive is for one-time use. Avoid re-using the adhesive to
ensure its adhesion.
2. Route the wires through the bracket (if there are existing wires) .
Wipe o the dust from the surface using a dry cloth, stick the bracket
with adhesive to the smooth wall, and press it down for 15 seconds
to ensure the bracket is rmly attached.
Note: This is applicable with tile, glass, marble, metal, stainless steel, and
smooth wall surfaces.
