-29-
correct and your network is connected well. Consult your ISP if
this problem remains.
IP Address:
Displays the IP address assigned by your ISP.
Subnet Mask:
Displays the Subnet Mask assigned by your ISP.
Default Gateway:
Displays the IP address of the default gateway assigned by your
ISP.
Note:
To ensure the BigPond connection re-established normally, please restart the connection at least 5
seconds after the connection is off.
3.1.4 LAN
3.1.4.1 LAN
On this page, you can configure the parameters for LAN port of this router.
Choose the menu Network→LAN→LAN to load the following page.
Figure 3-13 LAN
The following items are displayed on this screen:
¾ LAN
IP Address:
Enter the LAN IP address of the router. 192.168.0.1 is
the default IP address. The Hosts in LAN can access
the router via this IP address. It can be changed
according to your network.
Subnet Mask:
Enter the Subnet Mask. The default subnet mask is
255.255.255.0.
